OKMO 12V 15Ah LiFePO4 Lithium Battery 4000+ Deep Cycles for Kayak Fish Finder
- $43.95
$59.99- $43.95
- Unit price
- per
🔥 Core Product Advantages
1. Extreme Longevity, Top Value:
"Over 4,000 deep discharge cycles, offering 5-10x the lifespan of ordinary batteries." This is the core selling point, highlighting exceptional long-term cost-effectiveness, ideal for high-frequency cycling applications.
3. Wide-Temperature & High-Power Performance:"Operates reliably even at -20°C, with stable 15A continuous output." Emphasizes outstanding environmental adaptability and power performance for demanding applications like outdoor energy storage, RVs, backup power, and power tools.
3. Safe & Reliable, Comprehensive Protection:"IP65 dust/water resistance + flame-retardant case, intelligent BMS with multi-level protection." Addresses safety concerns by highlighting robust physical and electronic protection systems.
4. Flexible & Scalable, Versatile Application:"Ready to use as a single unit, and capable of series/parallel connections for easy upgrades to 24V/48V systems." Meets future expansion needs, enhancing the product's application potential and value.
5. Lightweight & Compact, Plug-and-Play:"Half the weight of lead-acid batteries with equivalent capacity, compact size for easy installation." For users replacing lead-acid batteries, emphasizes advantages in weight reduction and space savings.
🔥 Parameter Summary
1. Basic Performance
Model & Specifications:JCY-1215, Lithium Iron Phosphate (LiFePO4) cells.
Core Electrical Parameters:Nominal voltage 12.8V, rated capacity 15Ah, energy 192Wh.
Weight & Dimensions:: Approximately 1.6 kg (3.53 lbs), compact design (~151mm x 99mm x 95mm), highly portable.
2. Cycle Life & Warranty (Core Advantage)
Exceptional Cycle Life: Supports deep cycling, offering over 4,000 cycles at 100% Depth of Discharge (DOD). With partial cycles (e.g., 60% DOD), lifespan can reach 15,000 cycles, far exceeding lead-acid and some other lithium batteries.
Warranty Policy: Comes with a 2-year standard warranty, extendable to 3 years upon registration, demonstrating strong confidence in product reliability.
3. Charge/Discharge & Protection Performance
Charge/Discharge Currents:Standard charge/discharge currents are 3A/7.5A. Supports a maximum continuous discharge current of 15A, suitable for higher-power devices.
Voltage Protection Points:Discharge cut-off at 8.8V, over-discharge recovery at 10.8V, charge voltage at 14.4V, all precisely managed by the BMS.
Temperature Tolerance:Wide discharge temperature range of -20℃ ~ 60℃, suitable for harsh environments. Charging must be above 0°C.
BMS Features:Integrated 15A BMS provides protections against overcharge, over-discharge, overcurrent, and short circuits. Includes LTCP function (Long Time Connection Protection) to prevent damage from prolonged idle periods.
4. Construction & Expandability
Protection & Material:Housing made of flame-retardant ABS plastic with a high protection rating of IP65 (dust-tight and protected against water jets), ensuring safety for outdoor use.
Expandability:Supports up to 4 series 4 parallel (4S4P) expansion. For example, a 4 parallel 2 series (4P2S) configuration yields a 24V/25.6V 60Ah (~1536Wh) battery pack, meeting higher voltage and energy needs.
5. Recommended Charge Controller Settings (Important Note)
Charging Settings:Constant Voltage/Bulk/Boost voltage should be set to 14.4V, Over Voltage Disconnect to 14.6V.
Discharge Settings:Low Voltage Disconnect should be set to 8.8V, Under Voltage Recovery to 10.8V. These settings match the battery's internal protection parameters, ensuring optimal safety and lifespan.
View More
Please hurry! Only 0 left in stock
151D
8H
23M
0S
Subtotal:
$43.95
10 customers are viewing this product
Couldn't load pickup availability
5 Years Warranty
Provides five years of online service and offline repair
30 Day Price Guarantee
If the price drops within 30 days, we'll refund the difference.
30 Days Free Returns
30 day no-questions-asked free return policy
Local Warehouse Free Shipping
Delivery within 2-5 days from order placement
-
【Superior Performance】: The OKMO 12V 15Ah LiFePO4 battery is the perfect replacement for traditional lead-acid batteries, offering higher energy density, better stability, and increased power. It's also significantly lighter at just 3.5 lbs, only a third of the weight of lead-acid batteries.
- 【Extended Lifespan】: Offering over 4000 cycles and a 10-year lifespan, this battery supports 100% Depth of Discharge (DOD) and State of Charge (SOC), delivering superior performance. You can also connect in series or parallel for up to 4P4S expansion.
- 【Advanced Protection & Low-Temperature Safety】: Equipped with a 12A Battery Management System (BMS), it provides overcharge, over-discharge, overcurrent, overheating, and short-circuit protection. The Low-Temperature Charging Protection (LTCP) feature ensures reliable performance.
- 【Safety & Eco-Friendly】: CE, ROHS, and FCC certified, our LiFePO4 battery ensures top-tier safety with no risk of fire or explosion. Free from heavy and rare metals, it’s environmentally sustainable. Designed for stable performance in both high and low extreme temperatures, it’s safe for indoor and outdoor use.
- 【Versatile Applications】: The OKMO 12Ah LiFePO4 battery powers a range of devices, including fish finders, electric scooters, LED lights, mobile devices, fans, alarm systems, outdoor camping gear, laptops, power wheels, small UPS systems, and ham radios. It also works with your solar panels.
BATTERY
| Cell Type: | LiFePO4 | |
| Nominal Voltage: | 12.8V | |
| Rated Capacity: | 15Ah | |
| Energy: | 192Wh | |
| Warranty: | 3-year warranty, plus 2-year extended with registration | |
| Cycle Life: | 4000 cycles at 100% DOD,6000 cycles at 80% DOD,15,000 cycles at 60% DOD | |
| Battery Management System (BMS)Board: | 15A | |
| Charge Method: | CC/CV | |
| Charge Voltage: | 14.4±0.2V | |
| Standard Discharge Current: | 7.5A | Recommended Charge Current: | 3A | Discharge Cut-off Voltage: | 8.8V | Over-discharge Recovery Voltage: | 10.8V | Max.Continuous Charge Current: | 7.5A | Max.Continuous Discharge Current: | 15A | Max.Continuous Output Power: | 192W | Weight: | 3.53 lbs | Dimension: | 151(L) x 99(W) x 9(H) mm,5.94(L) x 3.90(W) x 3.74(H) in | Housing Material: | ABS (Flame Retardant Plastic) | Protection Class: | IP65 | Recommended Terminal Torque: | / | Temperature Range: | Charge:0℃～45℃,Discharge:-20℃～60℃,Storage:-10℃～45℃ | PLTCP Function: | Yes | Max. Expansion (Parallel & Series): | 4S4P |
Charging
| Charge /Bulk /Boost Voltage: | 14.4V | |
| Absorption Voltage: | 14.4V | |
| Over Voltage Disconnect: | 14.6V | |
| Over Voltage Reconnect: | 13.6V | |
| Tail Current: | 0.3A |
Discharging
| Under Voltage Warning: | / | |
| Under Voltage Recover: | 10.8V | |
| Low Voltage Disconnect: | 8.8V | |
| Low Voltage Reconnect: | 10.8V |
4P2S
| Battery System: | 24V((25.6V)60Ah | |
| Energy: | 1536Wh | |
| Max.Continous Charge / Discharge Current: | 15A | |
| Max.Continous Load Power: | / |
We accept Purchase orders from various distributors, contractors, schools, universities, government institutions, and others.
To make a purchase order, please send the purchase order to us via e-mail at support@okmotech.com and we will have your order processed within 24 hours. We accept multiple terms of payment including credit cards, checks, PayPal, & government cards.
For more questions regarding purchase orders, feel free to email our sales department at : support@okmotech.com
FAQ
Q: What is the best way to check the battery's performance and current status?
>
The best way to check the battery's performance and status is by using the Bluetooth connectivity feature, which allows you to monitor the battery's voltage, current, charge level, and health directly via the mobile app (OKMO Bluetooth App). You can also check the battery’s internal protection system and make adjustments as needed.
Q: What are the steps to follow after receiving a new battery?
>
1. Inspect the battery for any physical damage during shipping.
2. Ensure the battery is at a safe voltage level for first use (if necessary, charge it to an optimal level).
3. Download the OKMO Bluetooth App to monitor the battery.
4.Connect the battery to your system (solar, off-grid, etc.) or device following manufacturer guidelines.
5. Start using the battery, ensuring it's placed in a well-ventilated area.
Q: Does this battery include features to protect against low temperatures?
>
Yes, OKMO's lithium batteries are equipped with an internal Battery Management System (BMS) that offers temperature protection. This includes protection against low and high temperatures, which helps prevent damage to the battery and ensures it operates efficiently in various environmental conditions.
Q: What is the maximum number of batteries I can connect in series or parallel?
>
The maximum number of batteries that can be connected in series or parallel depends on your specific configuration and the voltage requirements of your system. For example, when connecting in series, ensure the total voltage does not exceed the maximum voltage rating for your system. In parallel, you can connect multiple batteries to increase capacity, but ensure they are of the same type and voltage to avoid imbalances.
Q: What is the recommended method for charging a OKMO 12V 100Ah Bluetooth lithium battery?
>
The recommended charging method is to use a compatible lithium battery charger designed for 12V lithium batteries. Always use a charger with a proper charge profile (constant current/constant voltage) for lithium batteries. The charging voltage should be around 14.6V, with a maximum charge current that doesn’t exceed the battery's rated charging current (e.g., 0.2C or 20A for a 100Ah battery). Avoid overcharging or undercharging.
Q: How do Group 24 and Group 31 batteries differ in size and functionality?
>
Group 24 batteries are generally smaller (approximately 10.25 x 6.75 x 8.75 inches) and are used in applications like RVs, marine, and some solar systems.
Group 31 batteries are larger (approximately 12.2 x 6.8 x 8.8 inches) and provide more power capacity, making them ideal for larger setups like buses, boats, and larger solar systems.
Functionality-wise, Group 31 batteries tend to have a higher capacity, meaning they can store more energy and provide longer runtimes.
Q: Is it possible to install the battery in a non-upright position?
>
It is generally recommended to install lithium batteries like OKMO's in an upright position to avoid potential leakage or performance issues. However, some models may support installation in other orientations as long as they are kept within the manufacturer's guidelines for ventilation and safety. Always consult the product manual for specific installation instructions.
Q: Where can I find and download the OKMO Bluetooth App to manage my battery?
>
The OKMO Bluetooth App can be downloaded from both the Apple App Store (for iOS devices) and Google Play Store (for Android devices). You can search for "OKMO" in the respective app store to find and install the app, which will allow you to monitor and manage your battery's status and performance."
